CONVERTIDOR DC-DC STEP-UP 3-32V 5-35V

This is a DC to DC step-Up module based on LM2577 3A Step-Down Voltage Regulator. The LM2577 series of regulators are monolithic integrated circuits that provide all the active functions for a step-up(buck) switching regulator, capable of driving a 3A load with excellent line and load regulation. These devices are available in fixed output voltages of 3.3V, 5V, 12V(Default), and an adjustable output version.

Specification

• Module Properties: Non-isolated buck Module
• Rectification: Non-synchronous rectification
• Input voltage: 3V-32V
• Output voltage: 5-35V
• Input Current: 4A (MAX)
• Output Current: 2.5A (MAX)
• Module size: 49 (mm) x26 (mm)
• Input: 'IN+' input is Positive, 'IN-' type negative
• Output: 'OUT+' output is Positive, 'OUT-' type negative
